Designed for stacking up to 5.4 meters, order picking, and transport in high-intensity, multi-role applications, these platform stackers combine compactness with heavy-duty capabilities. Their fast, refined, and safety-assured performance ensures confident and highly productive operation.

Choose between folding platform (NSV) and fixed platform (NSF) versions. NSF models feature wraparound protective barriers with side (S) or rear (R) entry. Initial lift (I) variants are available for steep ramps and loading docks, capable of handling two pallets simultaneously—one on the load legs and one on the forks.

Wide straddle (S) models are ideal for closed-based pallets and other load carriers without open fork spaces.

Three steering options are available, each featuring the ergonomic emPower tiller head:

• Tiller-type: power steering via a short tiller arm
• Comfort Steering: power steering via a tiller head without an arm (similar to an electric scooter)
• Mechanical steering: non-powered, low-effort steering via a compact, simple, economical, and durable tiller arm
• Built on a stable and agile chassis, these stackers offer operator-centric design and technology, providing instant confidence. The user’s sense of balance, responsive control, and power remains consistent throughout every shift. Effective platform and mast damping enhance comfort all day long.

LOWER COST OF OPERATION

• Fully weather-protected and impact-resistant tiller head is sealed to IP65 standard and reinforced for high durability.
• Sealing of connectors, sensors, and other key components combines with robust construction, shock and accident resilience, long service intervals, and fast access features – including removable motor cover – to reduce maintenance needs and improve uptime.
• Durable design features include heavy-duty chassis, large-diameter drive wheel, protected display location, inductive operator presence sensors, and more, for long life with minimal servicing.
• Li-ion battery (if chosen) gives maximum lifespan, efficiency, and runtime. (Both Li-ion and lead-acid versions are available.)
• Advanced motors, regenerative braking, and efficient mast designs save on energy and hydraulic oil consumption.
• Standard display includes BDI (battery discharge indicator) to help prevent damaging deep discharge and support optimal timing of battery changes.
• Multifunctional display option offers clear information on truck and battery condition, faults and actions, and enables setting of operator IDs and PIN code access to avoid unauthorized truck use.
• High levels of component sharing maximize parts availability – and reduce downtime, stock, and carbon costs – across the Cat stacker and power pallet ranges.

UNMATCHED PRODUCTIVITY

• Initial lift (I) models allow clearance under load (197 mm from floor to top of load legs; 200 mm to top of forks) for easier working on steep ramps and loading docks.
• Double pallet handling capability halves the number of transport movements required. (Initial lift models.)
• Pallet-stopping heel on load legs helps align loads for much easier, faster, and safer double handling. (Initial lift models.)
• Wide straddle (S) models allow lowering of forks to the floor, between widely spaced support legs, for handling of closed-base pallets and other carriers without open fork spaces or pockets.
• Wide straddle structure simplifies fitting and use of specialized attachments such as roll clamps, spikes, and rotators, giving even greater application flexibility.
• Wide straddle variant specifications include choice of standard (855 or 1055 mm) or customized straddle widths, for optimum matching with applications.
• Wide straddle legs have tandem wheels and a low-profile design, slightly angled downward toward their endpoint, for improved drive-in and ground clearance and better performance on gradients.
• Fork shape is tapered on the underside as well as pointed at the tip, to avoid sticking, for easier and faster pallet entry and exit even while turning at the same time. (On wide straddle models, fork tips are slightly pointed and tapered.)
• Extensive mast choice includes duplex and triplex versions with a range of standard and custom lift heights, to match applications perfectly. (Triplex not available on wide straddle models.)
• Powerful and quiet hydraulic motor is smoothly governed by stepless, speed-regulated lifting and lowering control, for quick but safe and accurate fork positioning and movement.
• Creep speed feature increases load capacity for lifts above 1.7 m by automatically limiting travel to 5 km/h when forks reach that height. (Speed-cut height varies in wide straddle models.)
• Compact and lightweight chassis works with easy, accurate steering to allow rapid maneuvering and tight turns in narrow aisles.
• Fully integrated Li-ion technology makes continuous operation possible, without battery changes, using fast opportunity charging during short breaks. (Both Li-ion and lead-acid versions are available.)
• Quick battery lock together with bearing-mounted steel roller option speeds up changes. (For lead-acid batteries.)
• Exceptional levels of comfort, control, traction, and stability keep operators alert, motivated, and productive, however intense their workload.
• Three performance modes are selectable to suit individual users and applications: Power for advanced operators and intensive operations; Eco to blend low energy consumption with high productivity; Easy for learners and for handling sensitive goods. (Available only with multifunctional display option.)
• Latest AC drive motor technology combines high power with advanced electronic control, a large-diameter drive wheel, and strong regenerative braking for a confident, fast, smooth, and precisely controlled ride.

SAFETY AND ERGONOMICS

• Operator-centric chassis design optimizes traction according to load weight and maintains safe stability, while providing excellent maneuverability, for instant user confidence and continuous top-class performance in fast-paced, high-level stacking operations.
• Active Spin Reduction (ASR) option aids traction on slippery surfaces.
• Best-in-class emPower ergonomic tiller head gives easier access to controls with a unique patented design that achieves the optimum distance between hand and lift/lower buttons.
• Ergonomically designed tiller head operating features include optimized handle shape and cross-section, large hand space, and enlarged horn and lift/lower buttons, as well as user-friendly speed and brake controls.
• Butterfly-type, dual-direction speed and brake control design provides seven convenient finger positions for comfortable, low-effort, precise operation.
• Dual controls allow easy reach with either hand and can be used accurately even when wearing gloves.
• Tiller-type power steering via a short tiller arm features a hydraulic damper and works without physical connection to the drive wheel – avoiding transmission of bumps, twists, and turns, while enabling comfortable, controlled, precise maneuvering. (Available on folding platform and rear-entry fixed platform models.)
• Comfort Steering via a tiller head without an arm – as on an electric scooter – maximizes power-steered control and precision, with the aid of a damper, while avoiding shock, vibration, strain, and fatigue in the operator’s hands, wrists, and arms. (Available on fixed platform models.)
• Mechanical (non-powered) steering option uses a compact tiller arm to provide a simple, economical, durable, low-effort maneuvering solution for less intense work environments. (Only available on folding platform models.)
• Tiller up drive option allows maneuvering with tiller arm vertical, to move through the tightest spaces. (Available on folding platform models with mechanical or power steering.)
• Electronic steering technology automatically adjusts sensitivity according to steered angle and truck speed, and gives resistance and feedback, for controlled travel and full confidence. (On all power-steered trucks.)
• Cornering control constantly monitors steering angle, travel rate, and quickness of tiller head movement – automatically adjusting the turning speed to maintain safe motion. (On all power-steered trucks.)
• Mast and fork carriage design and engineering advances improve forward and fork-tip views, while enhancing the user experience with smoother, quieter lifting and lowering.
• Effective mast and fork carriage damping ensures soft landings, smooth stage transitions and rattle-free travel – allowing comfortable load handling and driving with maximum performance throughout long shifts.
• High-comfort damping on both folding and fixed platforms minimizes impacts on the knees, especially, and acts progressively with increasing operator weight, while ergonomic controls and steering further reduce effort and fatigue.
• Unique electrically adjustable damping option on fixed platform models is optimized for each operator’s weight and preference at the touch of a button, providing a cost-effective increase in comfort.
• Overhead guard protects operator from falling goods. (Standard on fixed platform models. Optional on folding platform models, but only with power steering.)
• Optional protective side bars on folding platform models are deployed quickly and simply – with one hand – to help avoid falls and defend against impacts. (Top speed is increased when side bars are used.)
• Fixed platform models give extra protection and comfort, with low step height – for easy entry/exit – and a choice of rear (R) and side entry (S) barrier designs.
• Optional foot protection system automatically slows/stops the truck if foot is outside platform. (Rear entry fixed platform models.)
• Rugged build includes compact but heavy-duty chassis, cast-iron platform, and integrated low-profile bumper to resist deformation, protect the operator, and reduce foot-trapping risk.
